Introduction

The Stainless Steel Water Bottle Printer is a specialized device designed for personalized printing on the surfaces of stainless steel water bottles; it is available for both bulk orders and custom configurations.

Parameter

Item	Specification
Product Name	Plastic Bottle Printer
Product Model	DF1
Product Diameter	45 mm – 125 mm
Printing Length	30 mm – 270 mm
Printhead	Toshiba CF3
Printhead Quantity	1 – 5 pcs
Printing Speed	As fast as 15 seconds per piece
Printing Precision	600 × 1800 DPI
Ink Colors	W, K, C, M, Y, Lc, Lm, V
Ink Drop Size	3.5 PL
Printing Mode	Color + White + Varnish
Printing Method	360° Rotary Printing
Taper Range	0 – 5°
Curing System	LED UV Lamp
Operation Software	RIPrint
Data Interface	Gigabit Ethernet
Supported Image Formats	TIFF, JPG, EPS, PDF, PNG, AI, PSD
Machine Dimensions	1950 × 870 × 1800 mm
Machine Weight	450 kg
Power Supply	50Hz AC220/110V ±10A (Ground Wire Required)
Certification	CE / ROHS / SGS
Working Temperature	20°C – 30°C
Working Humidity	30% – 60%
Applications	Cylindrical bottles, Conical bottles, Tumblers, Tapered containers, Tubes, Irregular-shaped bottles, Bowls, Aluminum cans

Features of Stainless Steel Water Bottle Printer

High-Precision Printing
The Stainless Steel Water Bottle Printer utilizes a Toshiba CF3 printhead, supporting 3.5 pL ink droplets and 1440 DPI resolution to deliver high-precision printing with crisp text and intricate patterns.

360° Seamless Printing
Equipped with a high-precision servo system, the device achieves a positioning accuracy of 0.1 mm, effectively eliminating pattern seams and ensuring that the design remains continuous and complete across the entire bottle surface.

High-Speed Production
With a minimum printing time of just 15 seconds per bottle, this equipment is ideally suited for large-scale mass production.

Customization

Customization Option	Description
Printhead Quantity	1–5 printheads, adjustable according to production requirements.
Ink Colors	White, Black, Cyan, Magenta, Yellow, Light Cyan, Light Magenta, and Transparent Varnish.
Printing Mode	Selectable single-color, four-color, or full-color plus varnish printing.
Bottle Compatibility	Supports cylindrical, conical, tumbler, tube-shaped, and irregular-shaped bottles.
Heating / UV Curing System	Temperature and LED UV lamp power fully adjustable.
Automation Level	Customizable for semi-automatic or fully automatic production lines.
Control Software	RIPrint interface with personalized parameter customization.

Suitable Materials for Printing

Stainless Steel, Aluminum Alloy, Titanium Alloy, Glass, and Specialty Plastics for Water Bottles

FAQ

Q: Are you a manufacturer or a trading company?

A: We are a professional manufacturer with our own production facilities.

Q: What is your delivery time?

A: Our standard delivery time is 15–30 days, depending on the order quantity and product type.

Q: What payment methods are accepted for samples?

A: We accept T/T (bank transfer) and Alipay.

Q: What kind of packaging do you provide?

A: Our products come with original factory packaging. We can also provide neutral packaging or customized packaging according to customer requirements.

Q: What is your sample policy?

A: If the product is in stock, we can provide samples. However, the customer needs to pay the sample fee and the express shipping cost.

Q: Do you test all goods before shipment?

A: Yes. All products undergo 100% testing before delivery, and we will provide detailed product photos for customer confirmation before shipment.

Q: How does the Stainless Steel Water Bottle Printer achieve high-precision printing?

A: By utilizing a Toshiba CF3 printhead and 3.5 pL ink droplets, it achieves a high resolution of 1440 DPI, ensuring that printed patterns feature crisp, clear details.

Q: How is continuous ink jetting ensured?

A: The device employs an ink circulation system to prevent printhead clogging and air bubbles, thereby guaranteeing color stability.

Q: Is it possible to save bottle profile parameters?

A: The system can store parameters for various bottle types, allowing for one-touch recall to minimize repetitive setup and adjustment time.

Q: How should the equipment be cleaned?

A: Wipe the printhead and conveyor components with a soft cloth and alcohol to prevent ink clogging.

Certificate

We have obtained CE, RoHS, and SGS certifications.
